Specifications
| Model | XLf 180 A |
| Speaker Size | 8" |
| Max Output Power | 450W |
| RMS Output Power | 180W |
| Built-in Amplifier Type | Class AB |
| Frequency Response | 30Hz-150Hz |
| Impedance | 2 Ω |
| S/N Ratio | 91dB |
| Input Sensitivity | RCA input 0.2V-10V/Speaker input 0.6V-12V |
| Low Pass Filter | 50Hz-150Hz |
| Operating Voltage | 14.4V(10V-16V) |
| Phase Switch | 0°/180° |
| Gain | 200mV-6V |
| Automatic ON/OFF | Hi-level Input Only |
| Fuse | 25A |
| Bass Boost | 0-18dB |
| Passive Radiator Size | 192x60mm x2 |
| Subwoofer Cone Material | Aluminum |
| Subwoofer Magnet Material | Ferrite |
| Enclosure Material | Sealed Cast Aluminum Enclosure |
| Dimensions | 345x260x75mm |
| Net Weight | 2.65kg |
